CC8521RHAT
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
RF Transceiver Wireless 2.4 GHz RF SoC
PDF
/
Buying Options
Total Price: USD $43.36
Unit Price: USD $43.35895
≥1 USD $43.35895
≥10 USD $35.57655
≥100 USD $34.46505
≥500 USD $33.3526
≥1000 USD $32.2411
Inventory: 1154
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 6mm
Length 6mm
Height 1mm
Technical
GPIO 15
Sensitivity (dBm) -86 dBm
Modulation 2FSK, 8FSK
Serial Interfaces I2C, I2S, SPI, USB
Data Rate (Max) 5Mbps
Sensitivity -90dBm
RF Family/Standard General ISM > 1GHZ
Power - Output 11dBm
Interface I2C, SPI
Number of Channels 2
Power Supplies 3.3V
Pin Count 40
Base Part Number CC8521
Frequency 2.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Subcategory Other Telecom ICs
Type TxRx + MCU
Number of Terminations 40
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series PurePath? Wireless
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 40
Package / Case 40-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
