CC430F6147IRGCR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC MCU 16BIT W/RF CORE 64VQFN
PDF
/
Buying Options
Total Price: USD $6.6
Unit Price: USD $6.603303
≥1 USD $6.603303
≥100 USD $5.285253
≥250 USD $4.115856
≥1000 USD $3.441939
Inventory: 1558
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Type TxRx + MCU
Subcategory Microcontrollers
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 300MHz~348MHz 389MHz~464MHz 779MHz~928MHz
Base Part Number CC430F6147
Pin Count 64
Interface I2C, IrDA, SPI, UART
Memory Size 32kB Flash 4kB SRAM
RAM Size 4kB
Bit Size 16
Watchdog Timer Yes
Has ADC YES
Data Bus Width 16b
Number of Timers/Counters 2
Density 256 kb
Core Architecture MSP430
Number of A/D Converters 8
Number of Programmable I/O 44
Power - Output 13dBm
RF Family/Standard General ISM < 1GHz
RAM (words) 4
Number of UART Channels 1
Data Rate (Max) 500kBaud
Serial Interfaces I2C, IrDA, JTAG, SPI, UART
Current - Receiving 15mA~18.5mA
Current - Transmitting 15mA~36mA
Modulation 2FSK, 2GFSK, ASK, MSK, OOK
Sensitivity (dBm) -117 dBm
Dimensions
Height 1mm
Length 9mm
Width 9mm
Thickness 880μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
