CC430F6143IRGCR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU ISM<1GHZ 64-VFQFN
PDF
/
Inventory: 4502
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Type TxRx + MCU
Terminal Finish NICKEL PALLADIUM GOLD
Subcategory Microcontrollers
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 300MHz~348MHz 389MHz~464MHz 779MHz~928MHz
Base Part Number CC430F6143
Pin Count 64
Interface I2C, SPI, UART
Memory Size 8kB Flash 2kB SRAM
Number of I/O 44
RAM Size 2kB
Bit Size 16
Watchdog Timer Yes
Data Bus Width 16b
Number of Timers/Counters 2
Core Architecture MSP430
Number of A/D Converters 8
Power - Output 13dBm
RF Family/Standard General ISM < 1GHz
Number of UART Channels 1
Data Rate (Max) 500kBaud
Serial Interfaces I2C, IrDA, JTAG, SPI, UART
Current - Receiving 15mA~18.5mA
Current - Transmitting 15mA~36mA
Modulation 2FSK, 2GFSK, ASK, MSK, OOK
Sensitivity (dBm) -117 dBm
Dimensions
Length 9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
