CC3220SM2ARGKR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
SIMPLELINK WI-FI WIRELESS
PDF
/
Buying Options
Total Price: USD $4.62
Unit Price: USD $4.62
≥1 USD $4.62
≥10 USD $4.23368
≥100 USD $3.848768
≥500 USD $3.463856
≥1000 USD $3.388
Inventory: 1237
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series SimpleLink?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Type TxRx + MCU
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature ALSO INCLUDEDE WI-FI NETWORK PROCESSOR
Technology CMOS
Voltage - Supply 2.1V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CC3220
Memory Size 256kB RAM
Number of I/O 27
Speed 80 MHz
Number of Bits 12
Peripherals I2C
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
Protocol 802.11b/g/n
Power - Output 18dBm
RF Family/Standard WiFi
Sensitivity -96dBm
Data Rate (Max) 54Mbps
Serial Interfaces I2C, SPI, UART
Current - Receiving 59mA
Current - Transmitting 223mA
Modulation DSSS, OFDM
GPIO 21
Dimensions
Height 1mm
Length 9mm
Width 9mm
Thickness 900μm
Compliance
RoHS Status ROHS3 Compliant
