CC3220MODASF12MONR
RoHS
RoHS compliant
RoHS compliantPackage 63-SMD Module
Category RF/IF and RFID / RF Transceiver ICs
Description
SimpleLink Wi-Fi? CERTIFIED? Wireless Module Solutions With Antenna 63-QFM -40 to 85
PDF
/
Buying Options
Total Price: USD $16.8
Unit Price: USD $16.7992
≥1 USD $16.7992
≥10 USD $15.19672
≥100 USD $13.996928
≥500 USD $12.797312
≥1000 USD $11.997462
Inventory: 1415
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Package / Case 63-SMD Module
Surface Mount YES
Number of Pins 63
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series SimpleLink?
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 63
ECCN Code 5A992C
Type TxRx + MCU
Technology CMOS
Voltage - Supply 2.3V~3.6V
Terminal Position UNSPECIFIED
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CC3220
Memory Size 1MB Flash 256kB RAM
Number of I/O 25
RAM Size 256kB
Has ADC YES
DMA Channels NO
PWM Channels NO
DAC Channels NO
Protocol 802.11b/g/n
ROM (words) 1024000
Power - Output 17dBm
RF Family/Standard WiFi
RAM (words) 256
Sensitivity -95dBm
Modulation DSSS, OFDM
Bus Compatibility I2C; I2S; SPI; UART
Number of GPIO 25
GPIO 21
Dimensions
Height 2.45mm
Length 25.5mm
Width 20.5mm
Thickness 2.4mm
Compliance
RoHS Status ROHS3 Compliant
