CC2652RB1FRGZR
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU 802.15.4 BLUETH
PDF
/
Buying Options
Total Price: USD $5.94
Unit Price: USD $5.94
≥1 USD $5.94
≥10 USD $5.3064
≥100 USD $4.775584
≥500 USD $4.351072
≥1000 USD $3.926525
≥3000 USD $3.523274
Inventory: 1474
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7mm
Length 7mm
Technical
GPIO 31
Modulation DSSS, O-QPSK
Current - Transmitting 7.9mA~10.2mA
Current - Receiving 7.3mA
Serial Interfaces ADC, GPIO, I2C, I2S, JTAG, SPI, UART
Data Rate (Max) 2Mbps
Sensitivity -102dBm
RF Family/Standard 802.15.4, Bluetooth
Power - Output 5dBm
On Chip Program ROM Width 8
ROM (words) 360448
Protocol Bluetooth v5.0, Thread, Zigbee?
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Bit Size 8
Speed 48 MHz
Number of I/O 31
Memory Size 352kB Flash 80kB RAM
JESD-30 Code S-PQCC-N48
Base Part Number CC2652
Frequency 2.4GHz~2.48GHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.8V~3.8V
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type TxRx + MCU
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
