CC2650F128RSMT
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU 802.15.4/BT 32QFN
PDF
/
Buying Options
Total Price: USD $6.35
Unit Price: USD $6.3536
≥1 USD $6.3536
≥10 USD $5.82296
≥100 USD $5.293728
≥500 USD $4.76432
Inventory: 713
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 900μm
Width 4mm
Length 4mm
Height 1mm
Technical
GPIO 10
Sensitivity (dBm) -100 dBm
Modulation DSSS, O-QPSK, GFSK
Number of Timers 4
Number of Serial I/Os 1
Current - Transmitting 6.1mA~9.1mA
Current - Receiving 5.9mA~6.1mA
Serial Interfaces I2C, I2S, JTAG, SPI, UART
Data Rate (Max) 1Mbps
Number of UART Channels 1
RAM (words) 28
RF Family/Standard 802.15.4, Bluetooth
Integrated Cache YES
Power - Output 5dBm
Format FIXED-POINT
Low Power Mode YES
Boundary Scan YES
CPU Family CORTEX-M3
Protocol 6LoWPAN, Bluetooth v5.1, Zigbee?
Density 1 Mb
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Bit Size 16
RAM Size 20kB
Speed 48 MHz
Number of I/O 10
Memory Size 128kB Flash 28kB SRAM
Interface I2C, SPI, UART
Base Part Number CC2650
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 2.4GHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.8V~3.8V
Technology CMOS
Type TxRx + MCU
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series SimpleLink?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Manufacturer Package Identifier RSM (S-PVQFN-N32)
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
