CC2650F128RGZR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 48-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description IC RF TXRX+MCU 802.15.4/BT 48QFN
PDF
/
Buying Options
Total Price: USD $5.52
Unit Price: USD $5.5176
≥1 USD $5.5176
≥10 USD $5.06088
≥100 USD $4.600288
≥500 USD $4.1404
≥1000 USD $3.79537
≥3000 USD $3.450322
Inventory: 1081
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Number of Pins 48

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series SimpleLink?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
ECCN Code 5A992C
Type TxRx + MCU
Technology CMOS
Voltage - Supply 1.8V~3.8V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CC2650
Memory Size 128kB Flash 28kB SRAM
Number of I/O 31
RAM Size 30kB
Bit Size 16
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
Density 1 Mb
Protocol 6LoWPAN, Bluetooth v5.1, Zigbee?
CPU Family CORTEX-M3
Boundary Scan YES
Low Power Mode YES
Format FIXED-POINT
Power - Output 5dBm
Integrated Cache YES
RF Family/Standard 802.15.4, Bluetooth
RAM (words) 28
Number of UART Channels 1
Sensitivity -100dBm
Data Rate (Max) 1Mbps
Serial Interfaces I2C, I2S, JTAG, SPI, UART
Current - Receiving 5.9mA~6.1mA
Current - Transmitting 6.1mA~9.1mA
Number of Serial I/Os 1
Number of Timers 4
Modulation DSSS, O-QPSK, GFSK
GPIO 31

Dimensions

Height 1mm
Length 7mm
Width 7mm
Thickness 900μm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
