CC2564BYFVR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 54-BGA, DSBGA
Category RF/IF and RFID / RF Transceiver ICs
Description RF Transceiver Bluetooth Cntlr
PDF
/
Buying Options
Total Price: USD $4.95
Unit Price: USD $4.9544
≥1 USD $4.9544
≥10 USD $4.422
≥100 USD $3.979712
≥500 USD $3.625864
≥1000 USD $3.272122
≥3000 USD $2.936067
Inventory: 2573
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 54-BGA, DSBGA
Number of Pins 54

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 54
Type TxRx Only
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Voltage - Supply 2.2V~4.8V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3.6V
Terminal Pitch 0.4mm
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CC2564
Operating Supply Voltage 4.8V
Interface UART
Protocol Bluetooth v4.1
Power - Output 12dBm
RF Family/Standard Bluetooth
Data Rate (Max) 4Mbps
Sensitivity (dBm) -95 dBm
Modulation GFSK, GMSK
Current - Transmitting 40.5mA~41.2mA
Current - Receiving 40.5mA~41.2mA
Serial Interfaces I2S, UART

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 2.93mm
Length 3.26mm
Height Seated (Max) 0.575mm
