CC2560AYFVT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 54-BGA, DSBGA
Category RF/IF and RFID / RF Transceiver ICs
Description RF Transceiver ECS Bluelink BT
PDF
/
Buying Options
Total Price: USD $5.75
Unit Price: USD $5.7456
≥1 USD $5.7456
≥10 USD $4.7139
≥100 USD $4.56665
≥500 USD $4.4194
≥1000 USD $4.27215
Inventory: 1846
Minimum: 1
-
+

Technical Details

Physical

Contact Plating Tin
Mounting Type Surface Mount
Package / Case 54-BGA, DSBGA

Technical

Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Type TxRx Only
Voltage - Supply 2.2V~4.8V
Frequency 2.4GHz
Base Part Number CC2560
Operating Supply Voltage 4.8V
Interface UART
Protocol Bluetooth v4.0
Power - Output 12dBm
RF Family/Standard Bluetooth
Data Rate (Max) 4Mbps
Serial Interfaces I2S, UART
Current - Receiving 40.5mA~41.2mA
Current - Transmitting 40.5mA~41.2mA
Modulation GFSK, GMSK
Sensitivity (dBm) -95 dBm

Compliance

RoHS Status ROHS3 Compliant

Alternative Model
