CC2538SF53RTQR
RoHS
RoHS compliant
RoHS compliantPackage 56-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF ZIGBEE/802.15.4 SOC HI PER
PDF
/
Buying Options
Total Price: USD $9.52
Unit Price: USD $9.5216
≥1 USD $9.5216
≥10 USD $8.72872
≥100 USD $7.935136
≥500 USD $7.141728
≥1000 USD $6.546531
≥3000 USD $5.951405
Inventory: 1213
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 56-VFQFN Exposed Pad
Number of Pins 56
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 56
Type TxRx + MCU
Voltage - Supply 2V~3.6V
Terminal Position QUAD
Number of Functions 1
Supply Voltage 3V
Frequency 2.4GHz
Base Part Number CC2538
Number of Channels 8
Interface I2C, SPI, UART, USB
Memory Size 512kB Flash 32kB RAM
RAM Size 32kB
Memory Type FLASH
Peripherals I2C
Data Bus Width 32b
Number of Timers/Counters 5
Protocol 6LoWPAN, Zigbee?
Core Architecture ARM
Power - Output 7dbm
RF Family/Standard 802.15.4
Data Rate (Max) 250kbps
Serial Interfaces I2C, JTAG, SPI, UART, USB
Current - Receiving 20mA~24mA
Current - Transmitting 24mA~34mA
Sensitivity (dBm) -97 dBm
GPIO 32
Dimensions
Height 1mm
Length 8mm
Width 8mm
Thickness 900μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
