CC2538NF23RTQR
RoHS
RoHS compliant
RoHS compliantPackage 56-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
ZigBee/802.15.4 Modules 2507MHz 250Kbps 56-Pin VQFN EP
PDF
/
Buying Options
Total Price: USD $5.88
Unit Price: USD $5.8824
≥1 USD $5.8824
≥10 USD $4.826
≥100 USD $4.6759
≥500 USD $4.52485
≥1000 USD $4.3738
Inventory: 1134
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 8mm
Length 8mm
Height 1mm
Technical
GPIO 32
Sensitivity (dBm) -97 dBm
Current - Transmitting 24mA~34mA
Current - Receiving 20mA~24mA
Serial Interfaces I2C, JTAG, SPI, UART, USB
Data Rate (Max) 250kbps
RF Family/Standard 802.15.4
Power - Output 7dbm
Protocol 6LoWPAN, Zigbee?
Density 0 b
Peripherals I2C
RAM Size 32kB
Memory Size 256kB Flash 32kB RAM
Interface I2C, SPI, UART, USB
Number of Channels 8
Base Part Number CC2538
Frequency 2.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 2V~3.6V
Type TxRx + MCU
ECCN Code 5A992.C
Number of Terminations 56
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Weight 200.005886mg
Number of Pins 56
Package / Case 56-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
