CC2531F256RHAR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 40-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description IC RF ZIGBEE/802.15.4 SOC W/ USB
PDF
/
Buying Options
Total Price: USD $5.58
Unit Price: USD $5.5792
≥1 USD $5.5792
≥10 USD $5.11368
≥100 USD $4.648512
≥500 USD $4.183696
≥1000 USD $4.092
Inventory: 828
Minimum: 1
-
+

Technical Details

Technical

GPIO 21
Number of GPIO 19
Sensitivity (dBm) -97 dBm
Current - Transmitting 28.7mA~33.5mA
Current - Receiving 20.5mA~24.3mA
Serial Interfaces SPI, USART, USB
Data Rate (Max) 250kbps
Number of UART Channels 1
RF Family/Standard 802.15.4
Power - Output 4.5dBm
Core Architecture 8051
Protocol Zigbee?
RAM Size 8kB
Memory Size 256kB Flash 8kB RAM
Interface SPI, USART, USB
Number of Channels 8
Pin Count 40
Base Part Number CC2531
Frequency 2.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 2V~3.6V
Type TxRx + MCU
Number of Terminations 40
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Weight 80.002354mg
Number of Pins 40
Package / Case 40-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Thickness 900μm
Width 6mm
Length 6mm
Height 1mm
