CC2530F256RHAT
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
TEXAS INSTRUMENTS CC2530F256RHAT IC, RF, ZIGBEE/802.15.4, SOC, 2.4GHZ
PDF
/
Buying Options
Total Price: USD $4.9
Unit Price: USD $4.9016
≥1 USD $4.9016
≥10 USD $4.49504
≥100 USD $4.086016
≥500 USD $3.677608
Inventory: 1124
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 900μm
Width 6mm
Length 6mm
Height 1mm
Technical
Sensitivity (dBm) -97 dBm
Current - Transmitting 28.7mA~33.5mA
Current - Receiving 20.5mA~24.3mA
Serial Interfaces SPI, USART
Number of ADC Channels 8
Data Rate (Max) 250kbps
Number of UART Channels 1
RF Family/Standard 802.15.4
Power - Output 4.5dBm
Core Architecture 8051
Protocol Zigbee?
Number of Timers/Counters 4
Data Bus Width 8b
Watchdog Timer Yes
Memory Type FLASH
RAM Size 8kB
Number of I/O 21
Memory Size 256kB Flash 8kB RAM
Interface 2-Wire, SPI, UART, USART
Pin Count 40
Base Part Number CC2530
Frequency 2.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 2V~3.6V
Type TxRx + MCU
ECCN Code 5A992.C
Termination SMD/SMT
Number of Terminations 40
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Weight 78.698276mg
Number of Pins 40
Surface Mount YES
Package / Case 40-VFQFN Exposed Pad
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
