CC2510F8RHHT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 36-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description IC RF TXRX+MCU ISM>1GHZ 36-VFQFN
PDF
/
Buying Options
Total Price: USD $5.44
Unit Price: USD $5.4384
≥1 USD $5.4384
≥10 USD $4.98608
≥100 USD $4.533056
≥500 USD $4.079592
Inventory: 277
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Thickness 900μm
Width 6mm
Length 6mm
Height 1mm

Technical

GPIO 21
Sensitivity (dBm) -103 dBm
Modulation 2FSK, GFSK, MSK
Current - Transmitting 15.5mA~26mA
Current - Receiving 14.7mA~22.9mA
Serial Interfaces I2S, SPI, USART
Data Rate (Max) 500kBaud
RF Family/Standard General ISM > 1GHZ
Power - Output 1dBm
Core Architecture 8051
Density 64 kb
Data Bus Width 8b
RAM Size 1kB
Memory Size 8kB Flash 1kB SRAM
Interface SPI, UART
Power Supplies 2.5/3.3V
Base Part Number CC2510
Frequency 2.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 2V~3.6V
Technology CMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type TxRx + MCU
Number of Terminations 36
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Number of Pins 36
Package / Case 36-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 weeks ago)
Factory Lead Time 12 Weeks
