CC2510F32RSP
RoHS
RoHS compliant
RoHS compliantPackage 36-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC, TRX, 2.4GHZ, 32K FLASH, QFN36
PDF
/
Buying Options
Total Price: USD $3.59
Unit Price: USD $3.591
≥1 USD $3.591
≥10 USD $2.9469
≥100 USD $2.85475
≥500 USD $2.7626
≥1000 USD $2.67045
Inventory: 30008
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Copper, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-VFQFN Exposed Pad
Number of Pins 36
Weight 92.589543mg
Technical
Operating Temperature -40°C~85°C
Packaging Tray
JESD-609 Code e4
Pbfree Code no
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
Termination SMD/SMT
Type TxRx + MCU
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 2.4GHz
Base Part Number CC2510
Pin Count 36
Operating Supply Voltage 3.3V
Interface SPI, USART, USB
Memory Size 32kB Flash 4kB SRAM
Number of I/O 21
RAM Size 4kB
Data Bus Width 8b
Number of Timers/Counters 3
Core Architecture 8051
Power - Output 1dBm
RF Family/Standard General ISM > 1GHZ
Data Rate (Max) 500kBaud
Serial Interfaces I2S, SPI, USART
Current - Receiving 14.7mA~22.9mA
Current - Transmitting 15.5mA~26mA
Modulation 2FSK, GFSK, MSK
Sensitivity (dBm) -103 dBm
Dimensions
Height 820μm
Length 6mm
Width 6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
