CC2510F16RSPRG3
RoHS
RoHS compliant
RoHS compliantPackage 36-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU ISM>1GHZ 36-VFQFN
PDF
/
Inventory: 7348
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 36-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 36
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
Type TxRx + MCU
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CC2510
Pin Count 36
Qualification Status Not Qualified
Power Supplies 2.5/3.3V
Interface RS-232, SPI, UART, USB
Memory Size 16kB Flash 2kB SRAM
RAM Size 2kB
Data Bus Width 8b
Density 128 kb
Core Architecture 8051
Power - Output 1dBm
RF Family/Standard General ISM > 1GHZ
Data Rate (Max) 500kBaud
Serial Interfaces I2S, SPI, USART
Current - Receiving 14.7mA~22.9mA
Current - Transmitting 15.5mA~26mA
Modulation 2FSK, GFSK, MSK
Sensitivity (dBm) -103 dBm
GPIO 21
Dimensions
Height Seated (Max) 0.9mm
Length 6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
