CC2431RTCR
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU 802.15.4 48-VFQFN
PDF
/
Buying Options
Total Price: USD $10.18
Unit Price: USD $10.184
≥1 USD $10.184
≥10 USD $8.3562
≥100 USD $8.09495
≥500 USD $7.8337
≥1000 USD $7.57245
Inventory: 2421
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Number of Pins 48
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Type TxRx + MCU
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Voltage - Supply 2V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Frequency 2.4GHz
Base Part Number CC2431
Pin Count 48
Interface SPI, USART
Memory Size 128kB Flash 8kB SRAM
Number of I/O 21
RAM Size 8kB
Memory Type FLASH
Data Rate 250 kbps
Data Bus Width 8b
Number of Timers/Counters 4
Protocol Zigbee?
Core Architecture 8051
RF Family/Standard 802.15.4
Serial Interfaces SPI, USART
Current - Receiving 27mA
Dimensions
Length 7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
