CC1201RHBR
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC TRANSCEIVER RF LP 32VQFN
PDF
/
Buying Options
Total Price: USD $4.28
Unit Price: USD $4.2768
≥1 USD $4.2768
Inventory: 18013
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 900μm
Width 5mm
Length 5mm
Height 1mm
Technical
GPIO 4
Sensitivity (dBm) -120 dBm
Modulation 2FSK, 2GFSK, 4FSK, 4GFSK, MSK, OOK
Current - Transmitting 33.6mA~54mA
Current - Receiving 19mA~23.6mA
Serial Interfaces SPI
Data Rate (Max) 1.25Mbps
RF Family/Standard General ISM < 1GHz
Power - Output 16dBm
Density 0 b
Memory Size 4kB ROM 256B RAM
Power Supplies 3V
Qualification Status Not Qualified
Base Part Number CC1201
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 164MHz~190MHz 410MHz~475MHz 820MHz~950MHz
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2V~3.6V
Subcategory Other Telecom ICs
Type TxRx + MCU
ECCN Code 5A992C
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 72.206235mg
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
