CC1125RHBR
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
RF Transceiver Ultra-Hi Perf RF Narrowbd Transceiver
PDF
/
Buying Options
Total Price: USD $5.41
Unit Price: USD $5.412
≥1 USD $5.412
≥10 USD $4.96056
≥100 USD $4.509824
≥500 USD $4.058824
≥1000 USD $3.72057
≥3000 USD $3.382333
Inventory: 2807
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 900μm
Width 5mm
Length 5mm
Height 1mm
Technical
GPIO 4
Sensitivity (dBm) -129 dBm
Modulation 2FSK, 2GFSK, 4FSK, 4GFSK, MSK, OOK
Number of Receivers 1
Current - Transmitting 26mA~56mA
Current - Receiving 17mA~27mA
Serial Interfaces SPI
Data Rate (Max) 200kbps
RF Family/Standard General ISM < 1GHz
Power - Output 16dBm
Density 0 b
Memory Size 4kB ROM 256B RAM
Power Supplies 3V
Qualification Status Not Qualified
Base Part Number CC1125
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 164MHz~192MHz 274MHz~320MHz 410MHz~480MHz 820MHz~960MHz
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2V~3.6V
Subcategory Other Telecom ICs
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type TxRx + MCU
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Digi-Reel?
Operating Temperature -40°C~85°C
Physical
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold, Silver
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
