CC1110F16RSPR
RoHS
RoHS compliant
RoHS compliantPackage 36-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
Tape & Reel (TR) CC1110 Surface Mount 2FSK ASK GFSK MSK OOK IC RF TxRx + MCU 6mm -112dBm 3V 10dBm
PDF
/
Buying Options
Total Price: USD $3.71
Unit Price: USD $3.7126
≥1 USD $3.7126
≥10 USD $3.0457
≥100 USD $2.9507
≥500 USD $2.8557
≥1000 USD $2.7607
Inventory: 10103
Minimum: 1
-
+
Technical Details
Technical
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
Type TxRx + MCU
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 300MHz~348MHz 391MHz~464MHz 782MHz~928MHz
Base Part Number CC1110
Pin Count 36
Power Supplies 3V
Memory Size 16kB Flash 2kB SRAM
RAM Size 2kB
Density 128 kb
Power - Output 10dBm
RF Family/Standard General ISM < 1GHz
Sensitivity -112dBm
Data Rate (Max) 500kBaud
Serial Interfaces I2S, USART
Current - Receiving 16.2mA~21.5mA
Current - Transmitting 18mA~36.2mA
Modulation 2FSK, ASK, GFSK, MSK, OOK
Sensitivity (dBm) -110 dBm
GPIO 21
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 36
Package / Case 36-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Dimensions
Height Seated (Max) 0.9mm
Length 6mm
Width 6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
