CC1101RTKR
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX ISM
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 9659
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad
Number of Pins 20
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code 5A991.G
Type TxRx Only
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Voltage - Supply 1.8V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Depth 4mm
Frequency 300MHz~348MHz 387MHz~464MHz 779MHz~928MHz
Base Part Number CC1101
Pin Count 20
Power Supplies 1.8/3.6V
Power - Output 12dBm
RF Family/Standard General ISM < 1GHz
Data Rate (Max) 600kbps
Serial Interfaces SPI
Current - Receiving 14.3mA~17.1mA
Current - Transmitting 12.3mA~34.2mA
Modulation 2FSK, 4FSK, ASK, GFSK, MSK, OOK
Sensitivity (dBm) -116 dBm
Dimensions
Height Seated (Max) 0.95mm
Length 4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
