CC1101RGPR
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
Low-Power Sub-1GHz RF Transceiver 20-QFN -40 to 85
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.68534
≥1 USD $0.68534
≥10 USD $0.64655
≥100 USD $0.60995
≥500 USD $0.57543
≥1000 USD $0.54286
≥3000 USD $0.51213
Inventory: 59906
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad
Number of Pins 20
Weight 69.994973mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Type TxRx Only
Subcategory Other Telecom ICs
Voltage - Supply 1.8V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Depth 4.15mm
Frequency 300MHz~348MHz 387MHz~464MHz 779MHz~928MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CC1101
Qualification Status Not Qualified
Density 0 b
Power - Output 12dBm
RF Family/Standard General ISM < 1GHz
Data Rate (Max) 600kbps
Serial Interfaces SPI
Current - Receiving 14.3mA~17.1mA
Current - Transmitting 12.3mA~34.2mA
Number of Receivers 1
Modulation 2FSK, 4FSK, ASK, GFSK, MSK, OOK
Sensitivity (dBm) -116 dBm
Dimensions
Height 1mm
Length 4mm
Width 4mm
Thickness 930μm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
