CC1021RSSR
RoHS
RoHS compliant
RoHS compliantPackage 32-VQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX ISM
PDF
/
Buying Options
Total Price: USD $5.6
Unit Price: USD $5.5974
≥1 USD $5.5974
≥10 USD $4.59325
≥100 USD $4.4498
≥500 USD $4.30635
≥1000 USD $4.1629
Inventory: 1535
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 7mm
Length 7mm
Height 1mm
Technical
GPIO 1
Sensitivity (dBm) -109 dBm
Modulation FSK, GFSK, OOK
Current - Transmitting 12.3mA~27.1mA
Serial Interfaces SPI, UART
Data Rate (Max) 153.6kBaud
RF Family/Standard General ISM < 1GHz
Power - Output 10dBm
Nominal Supply Current 19.9mA
Interface SPI, UART
Power Supplies 3V
Operating Supply Voltage 3V
Pin Count 32
Base Part Number CC1021
Frequency 402MHz~470MHz 804MHz~960MHz
Depth 7.1mm
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 2.3V~3.6V
Technology CMOS
Subcategory Other Telecom ICs
Type TxRx Only
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 32
Package / Case 32-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
