CC1020RUZ
RoHS
RoHS compliant
RoHS compliantPackage 32-VQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
Tray CC1020 SPI UART Surface Mount IC RF TxRx Only 7.1mm -118dBm 3V 10dBm
PDF
/
Buying Options
Total Price: USD $2.95
Unit Price: USD $2.9507
≥1 USD $2.9507
≥10 USD $2.42155
≥100 USD $2.34555
≥500 USD $2.26955
≥1000 USD $2.1945
Inventory: 1180
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 32-VQFN Exposed Pad
Number of Pins 32
Weight 72.206235mg
Technical
Operating Temperature -40°C~85°C
Packaging Tray
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
Type TxRx Only
Subcategory Other Telecom ICs
Voltage - Supply 2.3V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.65mm
Depth 7.1mm
Frequency 402MHz~470MHz 804MHz~960MHz
Base Part Number CC1020
Pin Count 32
Operating Supply Voltage 3V
Power Supplies 3V
Interface SPI, UART
Max Supply Current 1μA
Power - Output 10dBm
RF Family/Standard General ISM < 1GHz
Data Rate (Max) 153.6kBaud
Serial Interfaces SPI, UART
Current - Receiving 19.9mA
Current - Transmitting 12.3mA~27.1mA
Number of Receivers 1
Modulation FSK, GFSK, OOK
Sensitivity (dBm) -118 dBm
Dimensions
Length 7.1mm
Width 7mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
