CC1000-RTR1

Texas Instruments
RoHS
RoHS RoHS compliant
Package 28-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Transceiver ICs
Description RF Transceiver FSK 3V 28-Pin TSSOP T/R
PDF
/
Buying Options
Total Price: USD $10.56
Unit Price: USD $10.56495
≥1 USD $10.56495
≥10 USD $8.66875
≥100 USD $8.398
≥500 USD $8.12725
≥1000 USD $7.85555
Inventory: 7602
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status NRND (Last Updated: 4 days ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Number of Pins 28
Weight 117.508773mg

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Type TxRx Only
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 2.1V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.65mm
Depth 4.5mm
Frequency 315MHz 433MHz 868MHz 915MHz
Base Part Number CC1000
Pin Count 28
Operating Supply Voltage 3V
Power - Output 10dBm Max
RF Family/Standard General ISM < 1GHz
Data Rate (Max) 76.8kBaud
Serial Interfaces UART
Current - Receiving 7.4mA~9.6mA
Current - Transmitting 5.3mA~26.7mA
Number of Receivers 1
Modulation FSK
Sensitivity (dBm) -110 dBm

Dimensions

Height 1.2mm
Length 9.7mm
Width 4.4mm
Thickness 1mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
