CC1000-RTB1

Texas Instruments
RoHS
RoHS RoHS compliant
Package 28-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Transceiver ICs
Description TEXAS INSTRUMENTS CC1000-RTB1 RF TRANSCEIVER, SMD, TSSOP28, 1000
PDF
/
Buying Options
Total Price: USD $13.83
Unit Price: USD $13.82535
≥1 USD $13.82535
≥10 USD $11.34395
≥100 USD $10.9896
≥500 USD $10.6343
≥1000 USD $10.27995
Inventory: 7106
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status NRND (Last Updated: 1 week ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Number of Pins 28
Weight 117.508773mg

Technical

Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Type TxRx Only
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 2.1V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.65mm
Depth 4.5mm
Frequency 315MHz 433MHz 868MHz 915MHz
Base Part Number CC1000
Pin Count 28
Operating Supply Voltage 3V
Bandwidth 1 GHz
Power - Output 10dBm Max
RF Family/Standard General ISM < 1GHz
Data Rate (Max) 76.8kBaud
Serial Interfaces UART
Current - Receiving 7.4mA~9.6mA
Current - Transmitting 5.3mA~26.7mA
Number of Receivers 1
Modulation FSK
Sensitivity (dBm) -110 dBm

Dimensions

Height 1.2mm
Length 9.7mm
Width 4.4mm
Thickness 1mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
