STM32WB55CGU7
RoHS
RoHS compliant
RoHS compliantPackage 48-UFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
48-UFQFN Exposed Pad 30 Bluetooth v5.0Thread Zigbee? Surface Mount IC RF TxRx + MCU 7mm -100dBm 3V 6dBm
PDF
/
Buying Options
Total Price: USD $7.37
Unit Price: USD $7.3744
≥1 USD $7.3744
≥10 USD $6.66512
≥100 USD $6.355008
≥500 USD $5.517934
≥1000 USD $5.269942
≥3000 USD $4.804941
Inventory: 4550
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 48-UFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Type TxRx + MCU
Voltage - Supply 1.71V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 0.5mm
Reach Compliance Code compliant
Frequency 2.402GHz~2.48GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Memory Size 1MB Flash 256kB SRAM
Number of I/O 30
Speed 64 MHz
Bit Size 32
Has ADC YES
DMA Channels YES
PWM Channels YES
Protocol Bluetooth v5.0, Thread, Zigbee?
Power - Output 6dBm
RF Family/Standard 802.15.4, Bluetooth
Sensitivity -100dBm
Data Rate (Max) 2Mbps
Serial Interfaces I2C, SPI, UART, USART, USB
Current - Receiving 4.5mA~7.9mA
Current - Transmitting 5.2mA~12.7mA
Modulation GFSK
GPIO 30
Dimensions
Length 7mm
Width 7mm
Compliance
RoHS Status RoHS Compliant
