STA2500DTR
RoHS
RoHS compliant
RoHS compliantPackage 48-LFBGA
Category RF/IF and RFID / RF Transceiver ICs
Description
Bluetooth Class II 2.75V 48-Pin LFBGA T/R
PDF
/
Buying Options
Total Price: USD $4.05
Unit Price: USD $4.0508
≥1 USD $4.0508
≥10 USD $3.32405
≥100 USD $3.21955
≥500 USD $3.116
≥1000 USD $3.01245
Inventory: 1535
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Package / Case 48-LFBGA
Number of Pins 48
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Type TxRx + MCU
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Voltage - Supply 1.65V~2.85V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.75V
Terminal Pitch 0.8mm
Frequency 2.4GHz
Base Part Number STA2500
Pin Count 48
Operating Supply Voltage 2.75V
Interface I2C, SPI, UART
Protocol Bluetooth v2.1 +EDR
Power - Output 8dBm
RF Family/Standard Bluetooth
Data Rate (Max) 3Mbps
Serial Interfaces I2C, JTAG, SPI, UART
Current - Receiving 35.4mA
Current - Transmitting 23mA~35.4mA
Modulation 8DPSK, DQPSK, GFSK
Sensitivity (dBm) -88 dBm
GPIO 10
Dimensions
Height Seated (Max) 1.25mm
Length 6mm
Width 6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
