STA2500DCTR

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 48-LFBGA
Category RF/IF and RFID / RF Transceiver ICs
Description Bluetooth Class II 2.75V 48-Pin LFBGA T/R
PDF
/
Inventory: 2012
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Surface Mount
Package / Case 48-LFBGA
Number of Pins 48

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Type TxRx + MCU
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Voltage - Supply 1.65V~2.85V
Terminal Position BOTTOM
Terminal Form BALL
Number of Functions 1
Supply Voltage 2.75V
Terminal Pitch 0.8mm
Frequency 2.4GHz
Base Part Number STA2500
Pin Count 48
Operating Supply Voltage 2.75V
Interface I2C, SPI, UART
Protocol Bluetooth v2.1 +EDR
Power - Output 8dBm
RF Family/Standard Bluetooth
Data Rate (Max) 3Mbps
Serial Interfaces I2C, JTAG, SPI, UART
Current - Receiving 35.4mA
Current - Transmitting 23mA~35.4mA
Modulation 8DPSK, DQPSK, GFSK
Sensitivity (dBm) -88 dBm
GPIO 10

Dimensions

Height Seated (Max) 1.25mm
Length 6mm
Width 6mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
