SN250QT
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU 802.15.4 48-VFQFN
PDF
/
Inventory: 2678
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case 48-VFQFN Exposed Pad
Number of Pins 48
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Type TxRx + MCU
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.39.00.01
Voltage - Supply 2.1V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Frequency 2.4GHz
Base Part Number SN250
Pin Count 48
Operating Supply Voltage 3.3V
Interface I2C, SPI, UART
Memory Size 128kB Flash 5kB SRAM
Protocol Zigbee?
Power - Output 5dBm
RF Family/Standard 802.15.4
Data Rate (Max) 12Mbps
Serial Interfaces I2C, SPI, UART
Current - Receiving 27mA~35.5mA
Current - Transmitting 19.5mA~35.5mA
Modulation O-QPSK
Sensitivity (dBm) -98 dBm
GPIO 17
Dimensions
Length 7mm
Width 7mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
