SI1034-A-GM
RoHS
/
Package 85-VFLGA Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
Tray 53 I2C SMBus SPI UART EZRadioPro IC RF TxRx + MCU 8mm -121dBm 3.3V 13dBm Max
PDF
/
Inventory: 8856
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 85-VFLGA Exposed Pad
Surface Mount YES
Number of Pins 85
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2000
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 85
ECCN Code 3A991.A.2
Type TxRx + MCU
Technology CMOS
Voltage - Supply 1.8V~3.8V
Terminal Position BOTTOM
Terminal Form BUTT
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 240MHz~960MHz
Pin Count 85
Operating Supply Voltage 3.3V
Interface I2C, SMBus, SPI, UART
Memory Size 128kB Flash 8.5kB RAM
Number of I/O 53
Speed 25 MHz
RAM Size 8.3kB
Memory Type FLASH
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
Protocol EZRadioPro
Core Architecture 8051
Power - Output 13dBm Max
RF Family/Standard General ISM < 1GHz
Data Rate (Max) 256kbps
Serial Interfaces I2C, SPI, UART
Current - Receiving 18.5mA
Current - Transmitting 17mA~30mA
Modulation FSK, GFSK, OOK
Sensitivity (dBm) -121 dBm
Dimensions
Length 8mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
