SI1014-A-GM
RoHS
/
Package 42-WFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU ISM<1GHZ 42WFQFN
PDF
/
Inventory: 5872
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 42-WFQFN Exposed Pad
Number of Pins 42
Weight 50.008559mg
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2000
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 42
Type TxRx + MCU
Subcategory Microcontrollers
Technology CMOS
Voltage - Supply 1.8V~3.6V
Terminal Position QUAD
Supply Voltage 4.5V
Frequency 240MHz~960MHz
Pin Count 42
Interface I2C, SMBus, SPI, UART
Memory Size 16kB Flash 768B RAM
Number of I/O 15
Speed 25 MHz
RAM Size 768B
Memory Type FLASH
Supply Current-Max 5mA
Bit Size 8
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 4
Protocol EZRadioPro
Core Architecture 8051
Power - Output 13dBm
RF Family/Standard General ISM < 1GHz
Number of UART Channels 1
RAM (bytes) 768
Data Rate (Max) 256kbps
Number of ADC Channels 18
Serial Interfaces I2C, SPI, UART
Current - Receiving 18.5mA
Current - Transmitting 17mA~30mA
Modulation FSK, GFSK, OOK
Sensitivity (dBm) -121 dBm
Dimensions
Height 700μm
Length 5mm
Width 7mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
