SI1013-C-GM2
RoHS
/
Package 42-VFLGA Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU ISM<1GHZ 42VFLGA
PDF
/
Buying Options
Total Price: USD $7.99
Unit Price: USD $7.9904
≥1 USD $7.9904
Inventory: 9362
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 7mm
Technical
Sensitivity (dBm) -121 dBm
Modulation FSK, GFSK, OOK
Current - Transmitting 17mA~30mA
Current - Receiving 18.5mA
Serial Interfaces I2C, SPI, UART
Data Rate (Max) 256kbps
RF Family/Standard General ISM < 1GHz
Power - Output 13dBm
Number of Programmable I/O 15
Core Architecture 8051
ROM (words) 8192
Protocol EZRadioPro
Number of Timers/Counters 4
Bandwidth 620 kHz
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Bit Size 8
Memory Type FLASH
RAM Size 768B
Speed 25 MHz
Number of I/O 15
Memory Size 8kB Flash 768B RAM
Interface I2C, SPI, UART
Frequency 240MHz~960MHz
Terminal Pitch 0.5mm
Supply Voltage 1.9V
Terminal Form BUTT
Terminal Position BOTTOM
Voltage - Supply 1.8V~3.6V
Technology CMOS
Type TxRx + MCU
Number of Terminations 42
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Not For New Designs
Published 2000
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 42
Surface Mount YES
Package / Case 42-VFLGA Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
