CYRF69303-40LFXC
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
Tray 40 PRoC? Surface Mount IC RF TxRx + MCU 6mm -90dBm 3V 0dBm
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.13943
≥1 USD $0.13943
≥200 USD $0.053957
≥490 USD $0.052061
≥980 USD $0.051124
Inventory: 9770
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 1mm
Technical
GPIO 15
Modulation DSSS, GFSK
Current - Transmitting 21.2mA~28.5mA
Current - Receiving 18.9mA~21.9mA
Serial Interfaces SPI
Data Rate (Max) 1Mbps
Sensitivity -90dBm
RF Family/Standard General ISM > 1GHZ
Power - Output 0dBm
Memory Size 8kB Flash 256B SRAM
JESD-30 Code S-XQCC-N40
Pin Count 40
Frequency 2.4GHz
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 3V
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~3.6V
Technology CMOS
Type TxRx + MCU
Number of Terminations 40
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series PRoC?
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 40-VFQFN Exposed Pad
Mounting Type Surface Mount
