2948B
RoHS
/
Package 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX WIFI 32VFQFN
PDF
/
Inventory: 5258
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.9mm
Technical
Modulation QPSK
Current - Transmitting 95mA~115mA
Current - Receiving 65mA~110mA
RF Family/Standard WiFi
Power - Output 6dBm
Protocol 802.11b
Supply Current-Max 0.136mA
Power Supplies 3/3.3V
Qualification Status Not Qualified
JESD-30 Code S-XQCC-N32
Pin Count 32
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 2.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~3.6V
Technology BICMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn/Pb)
Type TxRx Only
ECCN Code EAR99
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e0
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
