MKW22D512VHA5
RoHS
RoHS compliant
RoHS compliantPackage 63-VFLGA
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU 802.15.4 63-VFLGA
PDF
/
Buying Options
Total Price: USD $49.77
Unit Price: USD $49.76955
≥1 USD $49.76955
≥10 USD $40.8367
≥100 USD $39.5599
≥500 USD $38.28405
≥1000 USD $37.0082
Inventory: 1366
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8mm
Length 8mm
Technical
GPIO 2
Modulation DSSS, O-QPSK
Current - Transmitting 19mA
Current - Receiving 15mA
Serial Interfaces I2C, JTAG, SPI, UART, USB
Data Rate (Max) 250kbps
Sensitivity -102dBm
RF Family/Standard 802.15.4
Power - Output 8dBm
Protocol Zigbee?
PWM Channels YES
DMA Channels YES
Has ADC YES
Supply Current-Max 19.3mA
Speed 50 MHz
Number of I/O 27
Memory Size 512kB Flash 64kB SRAM
Power Supplies 1.8/3.3V
Qualification Status Not Qualified
Time@Peak Reflow Temperature-Max (s) 40
Frequency 2.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form BUTT
Terminal Position BOTTOM
Voltage - Supply 1.8V~3.6V
Technology CMOS
Subcategory Other uPs/uCs/Peripheral ICs
Type TxRx + MCU
Number of Terminations 63
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2006
Packaging Tray
Operating Temperature -40°C~105°C
Physical
Surface Mount YES
Package / Case 63-VFLGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
