MRF24XA-I/MQ
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
RF Transceiver 2.4GHz IEEE 802.15.4 Transceiver
PDF
/
Buying Options
Total Price: USD $33.31
Unit Price: USD $33.30795
≥1 USD $33.30795
≥10 USD $27.3296
≥100 USD $26.47555
≥500 USD $25.6215
≥1000 USD $24.76745
Inventory: 5305
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 5.1mm
Length 5.1mm
Height 950弮m
Technical
GPIO 3
Sensitivity (dBm) -95 dBm
Modulation DSSS, O-QPSK
Number of Receivers 1
Current - Transmitting 30mA
Current - Receiving 13.5mA~16.5mA
Serial Interfaces SPI
Data Rate (Max) 2Mbps
Sensitivity -103dBm
RF Family/Standard 802.15.4, General ISM > 1GHz
Power - Output 1dBm
Protocol 6LoWPAN, Zigbee簧, MiWi簧
Operating Supply Voltage 1.2V
Qualification Status Not Qualified
Base Part Number MRF24XA
Frequency 2.4GHz
Terminal Pitch 0.5mm
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.5V~3.6V
Subcategory Other Telecom ICs
Terminal Finish Matte Tin (Sn) - annealed
Type TxRx + MCU
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Published 2013
Packaging Tube
Operating Temperature -40簞C~85簞C
Physical
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
