MRF24J40-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
MICROCHIP - MRF24J40-I/ML - RF TRANSCEIVER, 2.405GHZ TO 2.480GHZ, QFN40
PDF
/
Buying Options
Total Price: USD $3.73
Unit Price: USD $3.7312
≥1 USD $3.7312
≥10 USD $3.432
≥100 USD $3.1064
Inventory: 1112
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 40-VFQFN Exposed Pad
Number of Pins 40
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2003
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
Type TxRx + MCU
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Other Telecom ICs
Voltage - Supply 2.4V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MRF24J40
Pin Count 40
Operating Supply Voltage 3.3V
Protocol Zigbee?, MiWi?
Power - Output 0dBm
RF Family/Standard 802.15.4
Data Rate (Max) 625kbps
Serial Interfaces SPI
Current - Receiving 19mA
Current - Transmitting 23mA
Number of Receivers 1
Modulation O-QPSK
Sensitivity (dBm) -95 dBm
GPIO 6
Dimensions
Height 950μm
Length 6mm
Width 6mm
Thickness 900μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
