ATWINC1510B-MU-T

Microchip Technology
RoHS
RoHS RoHS compliant
Package 40-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description Tape & Reel (TR) 40 I2C SPI UART 802.11b/g/n IC RF TxRx + MCU 5mm -89dBm 3.3V 20.5dBm
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.5552
≥1 USD $3.5552
≥10 USD $3.2648
≥100 USD $3.102
Inventory: 1166
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mounting Type Surface Mount
Package / Case 40-VFQFN Exposed Pad
Surface Mount YES

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2015
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
Type TxRx + MCU
Technology CMOS
Voltage - Supply 2.7V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3.3V
Terminal Pitch 0.4mm
Frequency 2.4GHz
JESD-30 Code S-PQCC-N40
Interface I2C, SPI, UART
Memory Size 8MB Flash 128kB ROM
Protocol 802.11b/g/n
Power - Output 20.5dBm
RF Family/Standard WiFi
Data Rate (Max) 72.2Mbps
Serial Interfaces I2C, SPI, UART
Current - Receiving 70.1mA
Current - Transmitting 294mA
Modulation CCK, DSSS, OFDM
Sensitivity (dBm) -89 dBm
GPIO 7

Dimensions

Height Seated (Max) 1mm
Length 5mm
Width 5mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
