ATWILC1000B-UU-Y

Microchip Technology
RoHS
RoHS RoHS compliant
Package 55-UFBGA, WLCSP
Category RF/IF and RFID / RF Transceiver ICs
Description SmartConnect Chipset WILC1000 - SmartConnect Chipset WINC1000
PDF
/
Inventory: 8220
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 3.25mm
Length 3.25mm

Technical

GPIO 9
Sensitivity (dBm) -98 dBm
Modulation CCK, DSSS, OFDM
Current - Transmitting 244mA~294mA
Current - Receiving 52.5mA~58.5mA
Serial Interfaces I2C, SDIO, SPI, UART
Data Rate (Max) 72.2Mbps
RF Family/Standard WiFi
Power - Output 20.5dBm
Protocol 802.11b/g/n
Memory Size 128kB ROM 224kB RAM
Interface I2C, SDIO, SPI, UART
JESD-30 Code S-PBGA-B55
Base Part Number ATWILC1000
Frequency 2.4GHz
Terminal Pitch 0.35mm
Supply Voltage 3.3V
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.62V~3.6V
Technology CMOS
Type TxRx + MCU
Number of Terminations 55
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Surface Mount YES
Package / Case 55-UFBGA, WLCSP
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
