ATSAMR35J16BT-I/7JX
RoHS
RoHS compliant
RoHS compliantPackage 64-TFBGA
Category RF/IF and RFID / RF Transceiver ICs
Description
Tape & Reel (TR) 16 LoRa? Surface Mount IC RF TxRx + MCU 6mm -148dBm 3.3V 20dBm
PDF
/
Buying Options
Total Price: USD $6.49
Unit Price: USD $6.4944
≥1 USD $6.4944
≥10 USD $6.336
Inventory: 1099
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Technical
Number of DMA Channels 16
GPIO 27
On Chip Data RAM Width 32
Number of External Interrupts 15
Modulation FSK, GFSK, GMSK, MSK, OOK
Number of Timers 3
Current - Transmitting 32.5mA~94.5mA
Current - Receiving 14.8mA~15.8mA
Serial Interfaces I2S, SPI, USART, USB
RAM (bytes) 8192
Sensitivity -148dBm
RAM (words) 2048
RF Family/Standard 802.15.4
Integrated Cache YES
Power - Output 20dBm
Low Power Mode YES
On Chip Program ROM Width 32
ROM (words) 16384
Protocol LoRa?
DMA Channels YES
Has ADC YES
Bit Size 32
Number of I/O 27
Memory Size 64kB Flash 8kB SRAM
JESD-30 Code S-XBGA-B64
Frequency 137MHz~175MHz 410MHz~525MHz 862MHz~1.02GHz
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.8V~3.63V
Technology CMOS
Type TxRx + MCU
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 64-TFBGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
