ATSAMR30E18A-MU
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
32 PIN SIP 256K MCU + 802.15.4 S
PDF
/
Buying Options
Total Price: USD $2.97
Unit Price: USD $2.968467
≥1 USD $2.968467
≥10 USD $2.590352
≥30 USD $2.364533
≥100 USD $2.137401
≥490 USD $2.032369
≥980 USD $1.985105
Inventory: 1378
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 1mm
Technical
Number of DMA Channels 12
Time-Min SECONDS
GPIO 16
On Chip Data RAM Width 32
Number of External Interrupts 14
Modulation BPSK, O-QPSK
Number of Timers 3
Current - Transmitting 26.5mA
Current - Receiving 9.2mA
Serial Interfaces I2C, SPI
Data Rate (Max) 1Mbps
Sensitivity -110dBm
RAM (words) 8192
RF Family/Standard 802.15.4
Integrated Cache YES
Power - Output 11dBm
Format FIXED-POINT
Low Power Mode YES
Boundary Scan YES
CPU Family CORTEX-M0
On Chip Program ROM Width 32
ROM (words) 65536
DAC Channels NO
PWM Channels NO
DMA Channels YES
Has ADC YES
Bit Size 32
Supply Current-Max 46mA
Speed 48 MHz
Number of I/O 16
Memory Size 256kB Flash 40kB SRAM
JESD-30 Code S-XQCC-N32
Base Part Number ATSAMR30
Frequency 700MHz 800MHz 900MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.8V~3.6V
Technology CMOS
HTS Code 8542.31.00.01
Type TxRx + MCU
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
