ATR2434-PLT
RoHS
/
Package 48-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RADIO TXRX 2.4GHZ ISM 48QFN
PDF
/
Inventory: 3654
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1mm
Technical
Modulation DSSS, GFSK
Current - Transmitting 69.1mA
Current - Receiving 57.7mA
Serial Interfaces SPI
Data Rate (Max) 62.5kbps
Sensitivity -95dBm (Max)
RF Family/Standard General ISM > 1GHZ
Power - Output 0dBm
Qualification Status Not Qualified
JESD-30 Code S-XQCC-N48
Time@Peak Reflow Temperature-Max (s) 30
Frequency 2.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 225
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~3.6V
HTS Code 8542.39.00.01
Type TxRx Only
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Published 1997
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
Alternative Model
