ATMEGA128RZBV-8CU
RoHS
RoHS compliant
RoHS compliantPackage 100-TFBGA
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU 802.15.4 100TFBGA
PDF
/
Buying Options
Total Price: USD $9.25
Unit Price: USD $9.2488
≥1 USD $9.2488
Inventory: 168
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
GPIO 86
Number of GPIO 86
Sensitivity (dBm) -101 dBm
Modulation O-QPSK
Current - Transmitting 9.5mA~16.5mA
Current - Receiving 15.5mA
Serial Interfaces I2C, JTAG, SPI, USART
Data Rate (Max) 250kbps
Sensitivity -101dBm
RF Family/Standard 802.15.4
Power - Output 3dBm
Protocol 6LoWPAN, Zigbee?
RAM Size 8kB
Memory Size 128kB Flash 4kB EEPROM 8kB SRAM
Interface I2C, SPI
Base Part Number ATMEGA128
Frequency 2.4GHz
Voltage - Supply 1.8V~3.6V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type TxRx + MCU
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2006
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Supplier Device Package 100-CBGA (9x9)
Number of Pins 100
Package / Case 100-TFBGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
