ATMEGA128RFR2-ZU

Microchip Technology
RoHS
RoHS RoHS compliant
Package 64-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description 2.4GHZ 802.15.4 128K SOC IND 85C
PDF
/
Buying Options
Total Price: USD $41.47
Unit Price: USD $41.47415
≥1 USD $41.47415
≥10 USD $34.02995
≥100 USD $32.9669
≥500 USD $31.90385
≥1000 USD $30.83985
Inventory: 1147
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Number of Pins 64

Technical

Operating Temperature -40°C~85°C
Packaging Tray
Published 2003
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Type TxRx + MCU
Subcategory Microcontrollers
Technology CMOS
Voltage - Supply 1.8V~3.6V
Terminal Position QUAD
Terminal Form NO LEAD
Terminal Pitch 0.5mm
Frequency 2.4GHz
Base Part Number ATMEGA128RFR2
Qualification Status Not Qualified
Power Supplies 2/3.3V
Interface SPI, USART
Memory Size 128kB Flash 4kB EEPROM 16kB SRAM
RAM Size 16kB
Memory Type FLASH
Bit Size 8
Watchdog Timer Yes
Data Bus Width 8b
Number of Timers/Counters 6
Protocol Zigbee?
Core Architecture AVR
Number of Programmable I/O 38
Power - Output 3.5dBm
RF Family/Standard 802.15.4
Data Rate (Max) 2Mbps
Number of ADC Channels 8
Serial Interfaces I2C, JTAG, SPI, USART
Current - Receiving 5mA~12.5mA
Current - Transmitting 8mA~14.5mA
Modulation DSSS, O-QPSK
Sensitivity (dBm) -100 dBm
Number of I2C Channels 1
GPIO 35

Dimensions

Height 850μm
Length 9mm
Width 9mm

Compliance

RoHS Status ROHS3 Compliant
