MAX2839ASEWO+T
RoHS
RoHS compliant
RoHS compliantPackage 73-WFBGA, WLBGA
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX CELLULAR 73WFBGA
PDF
/
Buying Options
Total Price: USD $12.51
Unit Price: USD $12.505187
≥1 USD $12.505187
≥10 USD $11.797348
≥100 USD $11.129572
≥500 USD $10.499598
≥1000 USD $9.905281
Inventory: 1162
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.61mm
Length 5.11mm
Height Seated (Max) 0.7mm
Technical
Modulation 16QAM, 64QAM
Current - Transmitting 116mA~145mA
Current - Receiving 79mA~120mA
Serial Interfaces SPI
RF Family/Standard Cellular
Power - Output 0dBm
Protocol WiMAX
Supply Current-Max 0.2mA
Power Supplies 3/3.3V
Operating Supply Voltage 3.6V
Qualification Status Not Qualified
Pin Count 73
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 2.3GHz~2.7GHz
Supply Voltage 2.8V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 2.7V~3.6V
Technology BICMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Type TxRx Only
ECCN Code 5A991
Number of Terminations 73
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 73
Surface Mount YES
Package / Case 73-WFBGA, WLBGA
Mounting Type Surface Mount
