DA14580-01AT2
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU BLUETOOTH 40VFQFN
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.015544
≥1 USD $1.015544
≥10 USD $0.944469
≥100 USD $0.917891
≥500 USD $1.7442
≥1000 USD $1.68625
Inventory: 45008
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.9mm
Technical
GPIO 24
Sensitivity (dBm) -93 dBm
Current - Transmitting 3.4mA
Serial Interfaces I2C, SPI, UART
RF Family/Standard Bluetooth
Power - Output -1dBm
Protocol Bluetooth v4.1
Max Supply Current 3.7mA
RAM Size 42kB
Memory Size 32kB OTP 84kB ROM 50kB SRAM
Interface I2C, SPI, UART
Operating Supply Voltage 3.3V
JESD-30 Code S-XQCC-N40
Frequency 2.4GHz
Reach Compliance Code unknown
Terminal Pitch 0.4mm
Supply Voltage 1V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.35V~3.3V
HTS Code 8542.39.00.01
Type TxRx + MCU
Number of Terminations 40
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2015
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C
Physical
Package / Case 40-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
