DA14580-01A32 image
Favorite
DA14580-01A32 image
Favorite
RoHS
RoHS RoHS compliant
Package 48-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description IC RF TXRX+MCU BLUETOOTH 48VFQFN
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14795
≥1 USD $2.14795
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 1131
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 6mm
Length 6mm
Height Seated (Max) 0.9mm

Technical

GPIO 32
Sensitivity (dBm) -93 dBm
Current - Transmitting 3.4mA
Current - Receiving 3.7mA
Serial Interfaces I2C, SPI, UART
RF Family/Standard Bluetooth
Power - Output -1dBm
Protocol Bluetooth v4.1
Memory Size 32kB OTP 84kB ROM 50kB SRAM
Interface I2C, SPI, UART
JESD-30 Code S-XQCC-N48
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 2.4GHz
Reach Compliance Code unknown
Terminal Pitch 0.4mm
Supply Voltage 1V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.35V~3.3V
HTS Code 8542.39.00.01
Type TxRx + MCU
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2006
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C

Physical

Surface Mount YES
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
