CYW20704UA2KFFB1G
RoHS
RoHS compliant
RoHS compliantPackage 49-VFBGA, FCBGA
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX+MCU BLUETOOTH 49VFBGA
PDF
/
Buying Options
Total Price: USD $6.15
Unit Price: USD $6.1512
≥1 USD $6.1512
≥10 USD $5.48856
≥100 USD $4.939616
≥500 USD $4.500434
≥1000 USD $4.06135
≥3000 USD $3.644256
Inventory: 4954
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Surface Mount
Package / Case 49-VFBGA, FCBGA
Surface Mount YES
Technical
Operating Temperature -30°C~85°C
Packaging Tray
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 49
Type TxRx + MCU
Technology CMOS
Voltage - Supply 3.3V
Terminal Position BOTTOM
Terminal Form BALL
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 2.4GHz
JESD-30 Code R-PBGA-B49
Protocol Bluetooth v4.1 +EDR
Power - Output 9dBm
RF Family/Standard Bluetooth
Sensitivity -96dBm
Data Rate (Max) 3Mbps
Serial Interfaces I2C, I2S, SPI, UART, USB
Current - Receiving 38mA
Modulation 4DQPSK, 8DPSK, GFSK
GPIO 8
Dimensions
Height Seated (Max) 1mm
Length 4.5mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
